Conveyor belt is the main part of a conveyor, which plays a role in loading and transporting materials, and which is widely used in metallurgy, construction materials, wharf, mining industries.
Conveyor belt is the main part of a conveyor, which plays a role in loading and transporting materials, and which is widely used in metallurgy, construction materials, wharf, mining industries. Compared with other mode of transportation, conveyor belt transportation has the following advantages, such as easy operation and maintainance , cheap freight, continuous transport of shorter distance. Conveyor belt transportation has already been the replacement of road and railway transportation.
In general conditions, this type of conveyor belt is suitable,for transporting lump, granular, powdery materials of normal temperature, non-corrosion.
1.Physical and Mechanical Properties of Rubber Cove
| Physical Properties Grade of Rubber Cover | Tensile Strength≥ | Breaking Elongation≥ | Abrasion Loss≤ |
| Mpa | % | mm3 | |
| H | 24.0 | 450 | 120 |
| D | 18.0 | 400 | 100 |
| L | 15.0 | 350 | 200 |
2.Full-thickness Tensile Properties
a.Longitudinal tensile strength not less than these nominal value:160,200,250,315,400,500,600,630,800N/mm
b.Full thickness breaking elongation not less than 10%。Full thickness, longitudinal elongation at reference force not more than 4%.
c.Straightness not more than 25mm
d.Ply adhesion：
| Ply to ply≥ | Rubber cover to ply | ||
| Rubber cover thickness≤1.5mm | Rubber cover thickness>1.5mm | ||
| All Samples average | 3.2N/mm | 2.1N/mm | 2.7N/mm |
We can manufacture endless belts as per clients' requirements, also along with patterns on rubber cover. If you are interested please feel free to contact thanks, we looking forward to communicate with you ~
